US 08 M 100 G3-T4 US-M8 Ultrasonic sensors

Name: US 08 M 100 G3-T4 US-M8 Ultrasonic sensors
Brand: Di-soric
SKU: us-08-m-100-g3-t4-us-m8-ultrasonic-sensors
Availability: InStock

Manufactured by

Di-soric

Authorized Partner

View Products

Inquiry Form

Get more information about US 08 M 100 G3-T4 US-M8 Ultrasonic sensors

Description

Ultrasonic sensor US-M8

US 08 M 100 G3-T4
Article Number: 210539

The US-M8 is the smallest ultrasonic sensor that can be integrated into machines very easily with its compact housing dimensions. At short ranges, the US M8 offers the highest degree of flexibility even with limited installation space, and is optimal for the modernization of systems.
IO-Link
Configurable as an ultrasonic sensor or barrier
3 different teach modes
Resistant to dirt
Extremely small design
Metal casing
Plug connector M8
Protection class IP 67

Collapse all

Service voltage18 … 30 V DC

No-load current (max.)30 mA (24 V DC)

Inverse polarity protectionYes

Short-circuit protectionYes

Insulation voltage endurance500 V

ThreadM8 x 1

Housing length70 mm

Transmission exitaxial

Assembly distance (sensor to sensor)60 mm

Housing materialBrass (CuZn, nickel-plated)

MaterialEpoxy resin, PUR (Transducer surface)

Weight10 g

Protection classIII, operation on protective low voltage

ApprovalsUL

Operating principleUltrasonic sensor, Ultrasonic barrier

Evaluationdigital

DesignThread

CharacteristicsIO-Link

Parallel operation possibleNo

Scope of deliverySensor, 2 x M8 nuts

FunctionsTeach (Pin 2), Out 1, IO-Link (Pin 4)

Switching outputPush-pull, 150 mA, NO/NC, switchable

Max. switch current150 mA

Voltage drop (max.)2 V

InterfaceIO-Link (V1.1, COM2 38.4 kBd, Smart Sensor Profile)

Nominal switching distance (Sn)100 mm

Range20 … 100 mm

Adjustment range20 … 100 mm (Teach in)

Resolution0.1 mm

Standardized measuring plate20 x 20 mm

Switching hysteresis (max.)1 … 5 mm (Adjustable by IO-Link)

Reproducibility< 0.3 mm

Sensitivity adjustmentRemote teach

DisplayLED green - Status, 1x yellow - Switching output

Ultrasonic frequency484 kHz

Switching frequency< 20 Hz

Readiness delay (max.)300 ms

Shock/vibration load30 g, 11 ms / 10 … 55 Hz, 1.0 mm

Ambient temperature during operation0 … +50 °C

Temperature drift0.2 %/K (uncompensated)

Temperature drift< 1 %/Sn (compensated)

Protection typeIP 67

ConnectionConnector, M8, 4-pin

Connection cableTK … /4
