OLE Q10 M 500 P1K-TSSL O-Q10 Miniature Optical sensors

Di-soric Optical sensors Industrial Automation - OLE Q10 M 500 P1K-TSSL O-Q10 Miniature Optical sensors

OLE Q10 M 500 P1K-TSSL O-Q10 Miniature Optical sensors

Di-soric logo

Manufactured by

Di-soric

Authorized Partner

View Products

Inquiry Form

Get more information about OLE Q10 M 500 P1K-TSSL O-Q10 Miniature Optical sensors

Description

Collapse all
Service voltage10 … 35 V DC
No-load current (max.)30 mA
Insulation voltage endurance500 V
Housing dimensions60 x 10 x 10 mm
Housing length10 mm
Housing height60 mm
Housing width10 mm
Housing materialDie-cast zinc (Black, painted)
MaterialGlass (Window)
Protection classIII, operation on protective low voltage
Operating principleThrough-beam sensor
Evaluationdigital
DesignCuboid design
Consisting ofReceiver
Switching outputpnp, 200 mA, NC
Voltage drop (max.)2.5 V
Light sourceLaser
Ambient light immunity5 kLx
Range0 … 500 mm
ResolutionØ 0.2 mm
Switching hysteresis (max.)0.1 mm
Reproducibility< 0.1 mm
Sensitivity adjustmentno setting elements
Switching frequency2000 Hz
Ambient temperature during operation0 … +50 °C
Protection typeIP 67
ConnectionConnector, M8, 3-pin
