Manufactured by
Omron
Authorized Partner
Description
The E5CB-R1TC is a compact LITE digital temperature controller from the dependable E5CB Series, designed for applications that require accurate temperature regulation with simple configuration. Its 1/16 DIN (48 × 48 mm) size makes it an excellent choice for space-saving installations in control panels and compact industrial equipment.
This controller supports both ON/OFF and PID control, allowing flexibility based on process requirements. It accepts thermocouple inputs across a wide temperature range, enabling use in various heating and process control applications. The relay control output allows direct switching of heaters, contactors, and other loads without the need for additional interface devices. A built-in alarm relay output enhances operational safety by providing alerts for abnormal temperature conditions.
Powered by a wide-range 100–240 VAC supply, the Omron E5CB-R1TC ensures stable and reliable operation in industrial environments. It is commonly used in heaters, ovens, packaging machines, laboratory equipment, and small automation panels where compact size and dependable performance are essential.
Specifications
- Brand: Omron
- Model / SKU: E5CB-R1TC
- Category: Temperature Controllers
- Series: E5CB Series
- Controller Type: LITE digital temperature controller
- Controller Size: 1/16 DIN (48 × 48 mm)
- Control Method: ON/OFF control, PID control
- Number of Control Loops: 1
- Temperature Input Type: Thermocouple (J, K, R, S, T)
- Temperature Range: -200 to 1700 °C
- Control Output: Relay output
- Alarm Outputs: 1 relay output
- Event Inputs: 0
- Power Supply: 100–240 VAC
- Terminal Type: Screw terminals
- Applications: Compact heaters, ovens, laboratory equipment, packaging machines, small automation panels
Why Choose Omron E5CB-R1TC?
- Compact 1/16 DIN design for space-constrained panels
- Supports both ON/OFF and PID temperature control
- Direct relay output for simple load switching
- Wide thermocouple compatibility and temperature range
- Reliable Omron performance for compact industrial systems
