E5AN-Q3MT-500-N

The E5AN-Q3MT-500-N is a 1/4 DIN basic digital temperature controller from the proven E5AN Series, designed for industrial applications requiring stable control, accurate measurement, and SSR-driven outputs. Operating on a wide-range AC 100–240 V power supply, this model has been widely deployed in control panels across manufacturing environments.

This controller features a universal input supporting both thermocouples and platinum resistance thermometers, making it suitable for a wide variety of temperature sensing needs. The voltage control output is specifically designed for driving solid-state relays (SSR), ensuring reliable and fast switching performance. With three auxiliary outputs, the E5AN-Q3MT-500-N enables alarms, status signaling, and interlock control within complex automation systems.

Known for its improved indication accuracy and 3-level display, the controller allows simultaneous monitoring of process value (PV), set value (SV), and manipulated value (MV). Although this model is now considered obsolete/end-of-life, it remains in demand for maintenance, replacement, and legacy system support, and is often sourced through surplus or refurbishment channels.

---

Specifications

• Brand: Omron
• Model / SKU: E5AN-Q3MT-500-N
• Category: Temperature Controllers
• Series: E5AN Series
• Controller Size: 1/4 DIN (96 × 96 mm)
• Controller Type: Basic digital temperature controller
• Input Type: Universal input (thermocouple / platinum resistance thermometer)
• Control Output: Voltage output for driving SSR
• Auxiliary Outputs: Three auxiliary outputs
• Display Type: 3-level display (PV, SV, MV)
• Indication Accuracy: ±0.3% of PV (thermocouple input)
• Operation Features: One-touch operation with PF key
• Maintenance Feature: Control output ON/OFF counter
• Power Supply: 100–240 VAC
• Terminal Cover: Included
• Version: New version (released after January 2008)
• Availability Status: Obsolete / end-of-life
• Applications: Industrial heating systems, furnaces, ovens, legacy automation panels, SSR-based temperature control systems

Why Choose Omron E5AN-Q3MT-500-N?

• Reliable SSR-driving voltage output for stable control
• Universal sensor compatibility for flexible integration
• High indication accuracy for precise temperature monitoring
• Multiple auxiliary outputs for alarms and control logic
• Ideal for replacement and support of existing E5AN-based systems
